SMD EQUAL LUMEN (WHITE)
We have complete supply chain, place your order here, we deliver to you!
Product Highlights
- These SMD strips feature constant-current IC for equal lumen from end to end with no voltage drop supporting super-long runs from a single power feed. IP ratings up to IP68 for reliable indoor/outdoor use. They deliver high lumen efficiency (ERP-compliant in H-E series)
≥50000 hours
UGR<19
SDCM＜5
3 times QC
Aging 4 hours
Key Features / 關鍵特徵
|
1. DRIVER / INPUT VOLTAGE
Constant Voltage LED Driver / AC100-240V 50/60Hz
|
2. LED Chip
SAN´AN CHIP CITIZEN CREE BRIGELUX
|
|
3. Material / Warranty
Silicone, PVC / 1-3year
|
4. Dimming Control
BLUETOOTH MESH, WI-FI, KNX, DALI-2,ZIGBEE3.0, PoE, PLC
|
|
5. Ingress Protection
IP20 IP44 IP65 IP68
|
6. Beam Angle / CRI
180°/ >80 >90 >95
|
|
7. CCT / COLOR
1800k - 6500k / white
|
8. LED Chip Model
SMD2835 SMD5050 SMD3528 SMD5730
|
9.Product List
| SERIES | Product No. |
Luminous Efficiency |
Wattage | LED Voltage |
LED Quantity |
Roll Length |
Cut Point |
PCB Width/Thickness |
|||
| SMD H-E ERP (WHITE) | HHS-120D | 80-100 lm/W | 7W | DC24V | 120pcs/m | 5/10m | 5cm | 5mm/2oz | |||
| HHS-120D | 80-100 lm/W | 10W | DC24V | 120pcs/m | 5/10m | 5cm | 8mm/2oz | ||||
| HHS-160D | 130-150 lm/W | 10W | DC24V | 160pcs/m | 5/10m | 5cm | 8mm/2oz | ||||
| HHS-238D | 120-140 lm/W | 20W | DC24V | 238pcs/m | 5/10m | 3cm | 10mm/2oz | ||||
| Usage examples: high-brightness task lighting e.g., kitchen, display cabines, storefronts | |||||||||||
| SMD EQUAL LUMEN (WHITE) | HHS-120D-20M | 90-110 lm/W | 9.6W | DC24V | 120pcs/m | 5/10m | 5cm | 10mm/2oz | |||
| HHS-140D-10M | 110-130 lm/W | 9.6W | DC24V | 140pcs/m | 5/10m | 5cm | 8mm/2oz | ||||
| HHS-280D-10M | 105-115 lm/W | 9.6W | DC24V | 280pcs/m | 5/10m | 5cm | 8mm/2oz | ||||
| 48V-120D-30M | 110-130 lm/W | 9.6W | DC48V | 120pcs/m | 5/10m | 5cm | 10mm/2oz | ||||
| 48V-120D-50M | 110-130 lm/W | 4.8W | DC48V | 120pcs/m | 5/10m | 5cm | 10mm/2oz | ||||
| Usage examples: Super long distance areas, e.g., corridors, building outlines. 24V is more suitable for cabinet edges, cabinet interior lighting, narrow slots, | |||||||||||
